| REFERENCE CODE |
OD x ID x L (mm) |
OD x ID x L (inch) |
| 012680-40-20, 1000002-40-20 |
7.14×1.02×50.8 |
.281"×.040"×2" |
|
7.14×0.76×55.0 |
.281"×.030"×2.165" |
| 015540 |
7.14×1.02×55.0 |
.281"×.040"×2.165" |
| 012680-30-30, 1000002-30-30, 002890-30-30 | 7.14×0.76×76.2 | .281"×.030"×3" |
| 012680-35-30, 1000002-35-30 | 7.14×0.89×76.2 | .281"×.035"×3" |
| 012680-40-30, 1000002-40-30, 002890-40-30 | 7.14×1.02×76.2 | .281"×.040"×3" |
| 012680-45-30, 1000002-45-30, 010345 | 7.14×1.14×76.2 | .281"×.045"×3" |
| 012680-47-30, 1000002-47-30 | 7.14×1.20×76.2 | .281"×.047"×3" |
| 012680-50-30, 010305 | 7.14×1.27×76.2 | .281"×.050"×3" |
| 012680-30-35 | 7.14×0.76×88.9 | .281"×.030"×3.5" |
| 012680-40-35 | 7.14×1.02×88.9 | .281"×.040"×3.5" |
| 012680-50-35, 002890-50-35 | 7.14×1.27×88.9 | .281"×.050"×3.5" |
| 012680-30-40, 1000002-30-40 | 7.14×0.76×101.6 | .281"×.030"×4" |
| 012680-35-40, 1000002-35-40 | 7.14×0.89×101.6 | .281"×.035"×4" |
| 012680-40-40, 1000002-40-40 | 7.14×1.02×101.6 | .281"×.040"×4" |
| 012680-50-40, 1000002-50-40 | 7.14×1.27×101.6 | .281"×.050"×4" |
| 012680-60-40, 1000002-60-40 | 7.14×1.52×101.6 | .281"×.060"×4" |
| 101470, 1000002-70-40 | 7.14×1.78×101.6 | .281"×.070"×4" |
